2.Mechanical life: ≥500,000 cycles
3.Electrical life: ≥ 200,000 cycles
4.Contact resistance: ≤50mΩ
5.Insulation resistance: ≥100MΩ(500VDC)
6.Dielectric strength: 1,500V，RMS 50Hz，1min
7.Operation temperature: -25 ℃~55℃ (+no freezing)
8.Operation pressure: About 1.5N
9.Operation travel: About 1.5mm
10.Torque: About 0.3Nm Max.applied to nut
11.Front panel protection degree: IP65 (IP67 made to order),IK07
12.MATERIAL:
Contact: Silver alloy
Button: Stainless steel
Body: Stainless steel
Base: PA
13. Circuit diagram
14.Terminal type: Pin terminal (2x0.5mm)
Customization
1.Mechanical Customization: Dimensions, Button Design, Mounting Structure, Tail Wiring + Connectors
2.Electrical Configuration： Momentary, Latching, Voltage Options, SPST/SPDT/DPST/DPDT
3.LED & Appearance： Laser Engraving, Illuminated Patterns, Button Cap / Housing / LED Colors, Head Shape, Surface Treatment， Contact Materials
4.Protection Options：IP65/IP67/IP68，Stainless Steel, Anti-Vandal, High/Low Temperature Materials, Oil-Resistant Materials
Customization options vary by product model. Please contact our sales team to confirm available configurations.
