1.Switch rating: Ui:250V，Ith:5A
2.Mechanical life: ≥200,000 cycles
3.Electrical life: ≥50,000 cycles
4.Contact resistance: ≤50mΩ
5.Insulation resistance: ≥100MΩ(500VDC)
6.Dielectric strength: 1,500V，RMS 50Hz，1min
7.Operation temperature: - 25 ℃~55℃ (+no freezing)
8.Operating pressure: About 4N
9.Operation travel: About 3 mm
10.Front panel protection degree: IP40/IP65
11.Terminal type: Pin terminal (2.8x0.5mm)/wire≈30cm
MATERIAL:
1.Contact: Silver alloy
2.Head: PBT
3.Body: PA
4.Base: PA
Customization
ONPOW undertakes a variety of custom needs for push-button development. Confirm whether packaging, marking or documentation OEM/ODM applies to LAS1-A22Y-11TSB(Short body) in the quotation.
Minimum order quantity, lead time and trade terms are not published here; confirm them with sales at sales@onpow.com.
