1.Switch rating: Ui:660V，Ith:10A
2.Mechanical life: ≥200,000 cycles
3.Electrical life: ≥50,000 cycles
4.Contact resistance: ≤50mΩ
5.Insulation resistance: ≥100MΩ(500VDC)
6.Dielectric strength: 3,000V，RMS 50Hz，1min
7.Operation temperature: -25 ℃~55℃ (+no freezing)
8.Operating pressure: About 20N
9.Operation travel: About 4.7mm
10.Front panel protection degree: IP40(IP65 made to order )
MATERIAL:
1.Contact: Silver alloy
2.Head: PA
3.Body: Zinc-aluminium alloy
4.Base: PBT
Customization
ONPOW undertakes a variety of custom needs for push-button development. Confirm whether packaging, marking or documentation OEM/ODM applies to HBY5-11TS in the quotation.
Minimum order quantity, lead time and trade terms are not published here; confirm them with sales at sales@onpow.com.
