1.Switch rating: Ui:250V，Ith:3A
2.Mechanical life: >=200,000 cycles
3.Electrical life: >=50,000 cycles
4.Contact resistance: <=50mΩ
5.Insulation resistance: >=100MΩ(500VDC)
6.Dielectric strength: 1,500V，RMS 50Hz，1min
7.Operation temperature: - 25 ℃~55℃ (+no freezing)
8.Lamp Type: Ring illuminated + Power symbol
9.Operation travel: About 2.8mm
10.Torque: About 0.6Nm
11.Front panel protection degree: IP40(IP65,IP67 can be choose)
12.Terminal type: 5 pin terminal
MATERIAL:
1.Contact: Silver alloy
2.Button: Nickel-plated Brass
3.Body: Nickel-plated Brass
4.Base: PA
