1.Switch rating: 24V/500mA
2.Electrical life: ≥50,000,000 cycles
3.Contact resistance: ≤20mΩ
4.Insulation resistance: ≥10MΩ(600VDC)
5.Operation temperature: -25 ℃~55℃ (+no freezing)
6.Operating Distance: 4~15cm (iferent distances with dfferent sensing objects)
7.Front panel protection degree: IP68
8.Wire Length：1.2m
MATERIAL:
1.Button: Stainless steel
2.Body: Stainless steel
3.Base: Epoxy resin
Customization
ONPOW undertakes a variety of custom needs for push-button development. Confirm whether packaging, marking or documentation OEM/ODM applies to ONPOW91-22E in the quotation.
Minimum order quantity, lead time and trade terms are not published here; confirm them with sales at sales@onpow.com.
